Wire Cut EDM Resin Mixed Bed Ion Exchange Resin, "Wire-Cut edm Resin","wire edm resin", "mixed bed resin", edm resin

Product Details

Wire Cut EDM Resin Mixed Bed Ion Exchange Resin can effectively remove metal impurities and ionized metal ions in working fluid, ensure the best conductivity of working fluid (water), stabilize cutting parameters of machine tool processing, and improve cutting accuracy and processing speed.

When used in EDM, you can be sure that the water dielectric is filtered to the purest and highest standard in the market. Wire Cut EDM Resin Mixed Bed Ion Exchange Resin can be used on all EDM machines using water as a dielectric fluid.

Wire Cut EDM Resin Mixed Bed Ion Exchange Resin is composed of gel type strong acid cation exchange resin and strong alkali anion exchange resin. Wire Cut EDM Resin Mixed Bed Resin is highly transformed and specially purified, and compounded according to specific chemical equivalents. And Wire Cut EDM Resin Mixed Bed Resin is suitable for the preparation of high purity water by WEDM and condensate water treatment system with the main purpose of removing ions and metal oxides. Wire-Cut edm Resin has the characteristics of high purity, large work exchange capacity and long service life.

With high regeneration degree.

Excellent kinetic properties

Extremely high exchange capacity

Excellent penetration resistance

Want to konw how we can do business ? Let's talk !

Technical Parameter

Item	Cation resin （H Type）	Anion resin (OH type)
Cation: Anion Resin Volume Ratio	1 : 1 (volume)
Appearance:	Yellow-brown spherical particles	Yellow spherical particles
Classification	Gel type	Gel type
Skeleton structure	Styrene series	Styrene series
Active groups	-SO3-	-N（CH3）3+
Degree of crosslinking %	7	5
Total exchange capacity (mmol/g) (dry)	≥5.0	≥3.8
Volume complete exchange capacity(mmol/ml)	≥1.75	≥1.1
Moisture content (%)	51.0~56.0	53.0～58.0
Particle size range mm	0.315～1.25	0.315～1.25
Uniform coefficient	≤1.60	≤1.60
Lower particle size（＜0.3mm）%	≤1	≤1
Upper grain size (＞1.0 mm)%	≤5	≤5
Bulk density (g/ml)	0.73~0.83	0.66~0.71
Specific density(g/ml)	1.25~1.30	1.06~1.10
Mean crush strength g/pcs	≥350	≥350
Crush strength (＞200g/pcs) %	≥90	≥90
Operating temperature ℃	≤50
Running flow rate m/h	10~90

Application

Water Treatment

Hard water softening and pure water preparation, high-purity water and ultra-pure water preparation, condensate purification, condensate polishing, wastewater treatment and heavy metal recovery.

MORE >

GET QUOTE

Food Processing

Removal of pesticide residues, patulin and harmful ions in fruit juice, purification of polyphenols, desalination, decolorization, refining and purification of sugar solution, dealkalization and purification of drinking water, removal of salts, acids, starch, monosodium glutamate in beverages , Refining of amino acids, citric acid, etc.

MORE >

GET QUOTE

Biopharmaceutics

Production, extraction, purification, purification, adsorption, separation and decolorization of antibiotics, vitamins and other drugs, adsorption and separation of biochemical products, separation and purification of biological protein drugs, blood purification, deep processing of Chinese herbal medicines, separation and purification of active ingredients of Chinese herbal medicines in plants.

MORE >

GET QUOTE

Hydrometallurgy

The separation, extraction and purification of rare metals, the enrichment and recovery of rare metals in wastewater, the recovery and treatment of waste acid, etc., the hydrometallurgical process summarizes the extraction of rare metals and comprehensive

MORE >

GET QUOTE

Petrochem Chemical Industry

Synthetic chemical reaction, polymerization reaction, etherification of ring chlorine, lipid hydrolysis, catalyst in the process, purification of organic reagents, degreasing of condensate water, separation, extraction, adsorption and removal of heavy metals, etc.

MORE >

GET QUOTE

Water Treatment

Food Processing

Biopharmaceutics

Hydrometallurgy

Petrochem Chemical Industry
